    M250AH Grinding Machine

    Ask Lasest Price
    Brand Name : Sanmore
    Model Number : M250AH
    Payment Terms : T/T, L/C
    Delivery Time : about 30 days
    • Product Details
    • Company Profile

    M250AH Grinding Machine

    M250AH Grinding Machine

    1. Adopt the exceeding precise class7(P4 level) ball bearing for spindle.

    2. Hydraulic system of table longitudinal movement.

    Technical ParametersUnitM250AH
    Max.workpiece to be Ground ( L×W×H)mm600×250×490
    Max. Grinding Lengthmm600
    Max. Grinding Widthmm250
    Distance From Table Surface To Spindle Centermm490
    Slide wayV-type rail with Steel-ball
    V-type rail with Steel-ballKg200
    Table Size (L×W)mm540×250
    Number of T -Slotmm×n12×1
    Speed OF Working Tablem/min3-23
    Cross Feed On Handwheelmm0.02/Graduation 2.5/revolution
    Vertical Feed On Handwheelmm0.01/Graduation 1.25/revolution
    Wheel Size (dia.×width×bore )mm200×16×31.75
    Spindle Speeds50Hzrpm2850
    0-6000
    Spindle MotorKw1.1
    Hydraulic station motorKw1.5
    Working PressureMpa3
    Max.CapacityL/min18
    Minimum Of NumericalL80
    Coolant PumpKw0.4
    Minimum of Numerical Displaymm
    Machine Size (L×W×H)mm1680×1220×1720
    Packing Size (L×W×H)mm1630×1290×1940
    Gross,NetT0.90, 0.95
